Key reminder & seat belt warning circuit for Jaguar XK II facelift 2 (2011-2014)

22 1 2 LIN HS CAN + HS CAN - 3 15 MS CAN + MS CAN - 31 32 25 HS CAN + HS CAN - DR SEAT BELT SW AJAR SW BLK WIRE BLK/GRN WIRE BLU WIRE BLU/ WHT WIRE BRK PAD WEAR BRK PAD WEAR RTN CAN (+) CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL) COMPUTER DATA LINES SYSTEM COUPE CRUISE CONTROL SYSTEM DOOR AJAR SWITCH 1 4 DRIVER DOOR SWITCH DRIVER SAFETY BELT SWITCH DRIVER'S DOOR LOCK ASSEMBLY DRIVER'S DOOR MODULE (IN DRIVER'S DOOR) FUSE 7 GRN WIRE HOT AT ALL TIMES IGN INSTRUMENT CLUSTER KEY-IN SWITCH LATCH GND LEFT FRONT PAD WEAR SENSOR (BEHIND LEFT FRONT FENDER LINER) MS CAN + NCA WIRE OUT PULL SWITCH REAR PAD WEAR SENSOR (UNDER RIGHT REAR SIDE OF VEHICLE) RED/WHT WIRE RESTRAINTS CONTROL MODULE (UNDER REAR OF CENTER CONSOLE) START CONTROL UNIT (UNDER CENTER CONSOLE) SW PULL WHT WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
