Jaguar XK II facelift 2 (2011-2014) w/ base audio Wiring diagram
This page shows the only wiring diagram for the component.w/ base audio, which is found in the car Jaguar XK II facelift 2 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ base audio (1 of 1)
2 1 FIBER OPTIC FIBER OPTIC MOST TX MOST RX
DAB TUNER MODULE
FIBER OPTIC
FIBER OPTIC FIBER OPTIC
FIBER OPTIC FIBER OPTIC 1 2 MOST RX MOST TX
FIBER OPTIC MOST RX
FIBER OPTIC MOST TX
FIBER OPTIC W/ DAB, W/O SATELLITE RADIO, NAVIGATION, PHONE FIBER OPTIC
FIBER OPTIC W/ NAVIGATION, W/O SATELLITE RADIO, PHONE, DAB FIBER OPTIC
FIBER OPTIC W/ PHONE, SATELLITE RADIO, FIBER OPTIC NAVIGATION, W/O DAB
FIBER OPTIC W/ SATELLITE, NAVIGATION, PHONE, FIBER OPTIC W/O DAB
FIBER OPTIC W/O NAVIGATION, SATELLITE RADIO, DAB, W/ PHONE FIBER OPTIC
FIBER OPTIC W/O SATELLITE RADIO, DAB, W/ FIBER OPTIC NAVIGATION, PHONE
IBOC RADIO MODULE
INFORMATION, ENTERTAINMENT CONTROL MODULE (CENTER OF INSTRUMENT PANEL)
INTEGRATED AUDIO MODULE (CENTER OF INSTRUMENT PANEL)
MOST RX MOST TX
MOST TEST CONNECTOR (UNDER LEFT SIDE OF DASH) 2 1 FIBER OPTIC FIBER OPTIC
NAVIGATION SYSTEM MODULE
PORTABLE INTERFACE AUDIO MODULE (RIGHT SIDE OF LUGGAGE COMPT)
POWER AMPLIFIER (PASSENGER'S FOOTWELL)
REAR OF LUGGAGE COMPT)
SDARS MODULE (BEHIND REAR SEAT BACK)
TELEPHONE MODULE (RIGHT SIDE OF LUGGAGE COMPT)
TOUCH SCREEN DISPLAY
W/ ANALOG AUDIO INTERFACE
W/ BASE AUDIO
W/ DIGITAL RADIO
W/ PHONE, DAB, NAVIGATION FIBER OPTIC
W/ PHONE, DAB, W/O NAVIGATION FIBER OPTIC
W/ PREMIUM AUDIO
W/ SATELLITE RADIO, FIBER OPTIC W/O NAVIGATION, PHONE, DAB
W/ SATELLITE, PHONE, W/O NAVIGATION, DAB FIBER OPTIC
W/O PHONE, FIBER OPTIC W/ NAVIGATION, DAB
Go to component -> Fibre optic network circuit -> W/ BASE AUDIO
