Jaguar XK II facelift 2 (2011-2014) rear heated window relay Wiring diagram
This page shows the only wiring diagram for the component.rear heated window relay, which is found in the car Jaguar XK II facelift 2 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear heated window relay (1 of 1)
12 13 COMPUTER DATA LINES SYSTEM CAN OUT + CAN OUT -
15 3 10 23 C- C+ MIRR HTR MIRR GND
2 13 B+ GND
AUTOMATIC TEMPERATURE CONTROL ECU (UNDER RIGHT END OF DASH)
B+ GND
B+ MS CAN C+
BATTERY JUNCTION BOX (LEFT SIDE OF BATTERY)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
C+ C- MIRR HTR MIRR GND
COMPUTER DATA LINES SYSTEM
CONVERTIBLE TOP LATCH MOTOR, REAR WINDOW HEATER ELEMENT
COUPE
DRIVER DOOR MODULE
DRIVER SIDE DOOR MIRROR
FUSE
FUSE 1
FUSE 13
FUSE 23
HOT AT ALL TIMES
MS CAN C+
NCA WIRE
ORG/YEL WIRE
PASSENGER DOOR MODULE (IN PASSENGER'S DOOR)
PASSENGER SIDE DOOR MIRROR
REAR HEATED WINDOW RELAY
REAR WINDOW HEATER ELEMENT
RED WIRE
TRANSIT MODE BYPASS CONNECTOR
WHT WIRE
YEL WIRE
Go to component -> Rear defogger & heated mirrors circuit -> REAR HEATED WINDOW RELAY
