Jaguar XK II facelift 2 (2011-2014) camera composite sync camera shield gnd Wiring diagram
This page shows the only wiring diagram for the component.camera composite sync camera shield gnd, which is found in the car Jaguar XK II facelift 2 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camera composite sync camera shield gnd (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 BATT
1 2 3 GVIF + GVIF - GVIF SCN
1 2 3 GVIF + GVIF - GVIF SHIELD
1 2 ANT ANT GND
1 2 FIBER OPTIC FIBER OPTIC MOST RX MOST TX
1 2 GPS ANT GPS ANT GND
1 2 PWR GND
1 2 SIG 1 SCN 1
1 2 SIG 2 SCN 2
1 2 SIG 3 SCN 3
1 2 VICS SENS VICS SENS GND
1 8 VBATT GND
2 1 ANT SCN ANT SIG
2 1 SCN SIG
AMP
ANALOGUE AUDIO BROADCAST
ANT PWR
ANTENNA AMPLIFIER
AUXILIARY JUNCTION BOX
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CAMERA COMPOSITE SYNC CAMERA SHIELD GND
COMPUTER DATA LINES SYSTEM
COUPE
DAB 1 2
FERRITE
FUSE
FUSE (BEHIND REAR SEAT BACKREST)
GPS ANTENNA (ON UNDERSIDE OF LIFTGATE)
GRN WIRE
HOT AT ALL TIMES
INTEGRATED AUDIO MODULE (CENTER OF INSTRUMENT PANEL)
NAVIGATION SYSTEM MODULE
NCA WIRE
PWR
REAR VIEW CAMERA
RED WIRE
TOUCH SCREEN DISPLAY
VBATT
VICS ANTENNA (IF EQUIPPED)
VIDEO NEG
VIDEO POS
W/ VICS RDS
W/O VICS RDS
YEL WIRE
Go to component -> Navigation circuit -> CAMERA COMPOSITE SYNC CAMERA SHIELD GND
