Jaguar XK II facelift 2 (2011-2014) 3 2 6 k line hs can - hs can + Wiring diagram
This page shows the only wiring diagram for the component.3 2 6 k line hs can - hs can +, which is found in the car Jaguar XK II facelift 2 (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 3 2 6 k line hs can - hs can + (1 of 1)
16 15 HS CAN + HS CAN -
2 3 HS CAN + HS CAN -
2 5 HS CAN - HS CAN +
3 2 6 K LINE HS CAN - HS CAN +
32 31 HS CAN - HS CAN +
4 3 HS CAN + HS CAN -
4 5 HS CAN+ HS CAN-
45 58 HS CAN - HS CAN +
6 5 HS CAN- HS CAN+
9 18 HS CAN - HS CAN +
9 8 HS CAN - HS CAN +
ABS MODULE (BEHIND LEFT FRONT FENDER LINER)
BLU WIRE
CONTINUOUSLY VARIABLE DAMPING MODULE (IF EQUIPPED)
CONVERTIBLE COUPE
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HEADLAMP CONTROL MODULE
HS CAN IN - HS CAN IN + K-LINE
ORG/ WIRE
PARKING BRAKE MODULE (BEHIND REAR SEAT BACKREST)
PEDESTRIAN PROTECTION MODULE (IF EQUIPPED) (BEHIND LEFT FRONT
RESTRAINTS CONTROL MODULE (UNDER REAR OF CENTER CONSOLE)
SEAT OCCUPANCY MODULE (UNDER FRONT PASSENGER'S SEAT)
SPEED CONTROL MODULE (IF EQUIPPED)
STEERING COLUMN LOCKING MODULE
TRANSMISSION CONTROL MODULE (RIGHT SIDE OF TRANSMISSION)
TRANSMISSION SHIFT MODULE
W/O PEDESTRIAN PROTECTION SYSTEM, W/ ADAPTIVE SPEED CONTROL
WHEEL ARCH LINER)
WHT WIRE
WHT/BLU WIRE
YAW RATE SENSOR (CENTER CONSOLE)
YEL WIRE
Go to component -> Diagnostic socket circuit (2 of 2) -> 3 2 6 K LINE HS CAN - HS CAN +
