Jaguar XK II facelift 2 (2011-2014) 22 1 2 lin hs can + hs can - Wiring diagrams
This page contains all the electrical diagrams for the component. 22 1 2 lin hs can + hs can -, in which he is found in the car Jaguar XK II facelift 2 (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 22 1 2 lin hs can + hs can - (1 of 2)
22 1 2 LIN HS CAN + HS CAN -
3 15 MS CAN + MS CAN -
31 32 25 HS CAN + HS CAN - DR SEAT BELT SW
AJAR SW
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/ WHT WIRE
BRK PAD WEAR BRK PAD WEAR RTN
CAN (+)
CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
COUPE
CRUISE CONTROL SYSTEM
DOOR AJAR SWITCH 1 4
DRIVER DOOR SWITCH
DRIVER SAFETY BELT SWITCH
DRIVER'S DOOR LOCK ASSEMBLY
DRIVER'S DOOR MODULE (IN DRIVER'S DOOR)
FUSE 7
GRN WIRE
HOT AT ALL TIMES
IGN
INSTRUMENT CLUSTER
KEY-IN SWITCH
LATCH GND
LEFT FRONT PAD WEAR SENSOR (BEHIND LEFT FRONT FENDER LINER)
MS CAN +
NCA WIRE
OUT
PULL SWITCH
REAR PAD WEAR SENSOR (UNDER RIGHT REAR SIDE OF VEHICLE)
RED/WHT WIRE
RESTRAINTS CONTROL MODULE (UNDER REAR OF CENTER CONSOLE)
START CONTROL UNIT (UNDER CENTER CONSOLE)
SW PULL
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Go to component -> Key reminder & seat belt warning circuit -> 22 1 2 LIN HS CAN + HS CAN -
Wiring diagram 22 1 2 lin hs can + hs can - (2 of 2)
1 2 3 4 5 6 SPLY GND LIN TRANSIT MODE
1 2 TIMER
18 7 22 START_STOP 2 START_STOP 1 GND
2 1 MON LIN
22 1 2 LIN HS CAN + HS CAN -
5 6 HS CAN + HS CAN -
ALTERNATOR
AUXILIARY JUNCTION BOX (BEHIND REAR SEAT BACKREST)
BATTERY JUNCTION BOX (LEFT SIDE OF BATTERY)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL
DIAGNOSTIC CONNECTOR (UNDER LEFT SIDE OF DASH)
DRIVER'S DOOR MODULE (IN DRIVER'S DOOR)
ENG CRANK
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
FUSE
FUSE 1
FUSE 13
FUSE 19
FUSE FUSE
GENERATOR
GRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
HOT AT ALL TIMES
IGN CTRL
INSTRUMENT CLUSTER
INTERNAL ELECTRONICS
JUMP
KL 30
LIN
MTR
ORG/GRN WIRE
PASSENGER DOOR MODULE (IN PASSENGER'S DOOR)
POST (UNDER LEFT REAR OF VEHICLE)
POWER DISTRIBUTION BOX (LEFT SIDE OF ENGINE COMPT)
PPL/ORG WIRE
RED WIRE
RED/WHT WIRE
SIG
SOL +
ST RLY + ST RLY - CAN - CAN + CRANK REQ PN SW IGN SW
START CONTROL UNIT (UNDER CENTER CONSOLE)
START SW 1
START SW 2
STARTER MOTOR
STARTER RELAY
SW SENS
SYSTEM
TRANSIT MODE
TRANSIT MODE- BYPASS CONNECTOR (CONNECT WHEN TRANSIT RELAY IS REMOVED)
TRANSIT RELAY (NEAR BATTERY)
TRANSMISSION SHIFT MODULE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Starting circuit -> 22 1 2 LIN HS CAN + HS CAN -
