Jaguar XJS Series 3 (1990-1996) left terminal post Wiring diagram
This page shows the only wiring diagram for the component.left terminal post, which is found in the car Jaguar XJS Series 3 (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left terminal post (1 of 1)
4.0L
6.0L
BATTERY (TRUNK)
BLK WIRE
BLK/GRN WIRE
BLK/LT GRN WIRE
BRN WIRE
GENERATOR (LEFT FRONT OF ENGINE)
IGNITION SWITCH
INHIBIT SWITCH (CENTER CONSOLE)
LEFT TERMINAL POST
NCA WIRE
NEUTRAL
OFF
PARK
POWER TOP SYSTEM
RIGHT TERMINAL POST
RUN WIRE
SECURITY CONTROL MODULE (RIGHT TAIL LIGHT CLUSTER)
STARTER MOTOR AND SOLENOID
STARTER RELAY
TRANSMISSION ROTARY PARK/ NEUTRAL SWITCH (LEFT SIDE OF GEARBOX)
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Starting circuit -> LEFT TERMINAL POST
