Jaguar XJS Series 3 (1990-1996) left quarter up relay Wiring diagrams
This page contains all the electrical diagrams for the component. left quarter up relay, in which he is found in the car Jaguar XJS Series 3 (1990-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left quarter up relay wiring diagram (1 of 3)
BLK WIRE
BLK/GRN WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/PPL WIRE
CONVERTIBLE TOP CONTROL MODULE
CONVERTIBLE TOP FUSE (NEXT TO CON- VERTIBLE TOP COMPONENT PANEL)
CONVERTIBLE TOP SWITCH
FUSE
GRN/BRN WIRE
GRN/PPL WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
IGNITION SWITCH
INSTRUMENT CLUSTER SYSTEM (PARK BRAKE INPUT)
LEFT QUARTER DOWN RELAY
LEFT QUARTER MOTOR
LEFT QUARTER UP RELAY
LT GRN/GRN WIRE
LT GRN/WHT WIRE
NCA WIRE
OFF
RIGHT QUARTER DOWN RELAY
RIGHT QUARTER MOTOR
RIGHT QUARTER UP RELAY
STARTING/CHARGING SYSTEM (START INHIBIT INPUT)
THERMAL BREAKERS
TOP DOWN RELAY
TOP MOTOR
TOP UP RELAY
WHT WIRE
WHT/PNK WIRE
Go to component -> Convertible top circuit -> LEFT QUARTER UP RELAY
left quarter up relay wiring diagram (2 of 3)
6.0L ONLY
A BANK OXYGEN SENSOR SHIELDS
AUXILIARY LOAD RELAY
B BANK OXYGEN SENSOR SHIELDS
BLK WIRE
CIGAR LIGHTER
CLIMATE CONTROL PANEL ILLUMINATION
CONVERTIBLE TOP CONTROL MODULE
COOLANT LEVEL TRANSMITTER
DRIVERS WINDOW SWITCH
FROM REVERSE LIGHT SWITCH
FROM RIGHT BLOWER
GEAR SELECTOR)
INTERIOR LIGHTING RELAY
LEFT QUARTER DOWN RELAY
LEFT QUARTER UP RELAY
MULTI FUNCTION UNIT
NCA WIRE
PASSENGER'S DOOR SWITCH PACK
PASSENGERS WINDOW SWITCH
RIGHT QUARTER DOWN RELAY
RIGHT QUARTER UP RELAY
SEAT HEATER RELAY
SECURITY LED
SECURITY SWITCH
TOP DOWN RELAY
TOP UP RELAY
Go to component -> Ground distribution circuit (7 of 8) -> LEFT QUARTER UP RELAY
left quarter up relay wiring diagram (3 of 3)
