Jaguar XJS Series 3 (1990-1996) delay fast speed normal speed Wiring diagram
This page shows the only wiring diagram for the component.delay fast speed normal speed, which is found in the car Jaguar XJS Series 3 (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram delay fast speed normal speed (1 of 1)
13 16 14 17 CS 3
AMBIENT TEMPERATURE SENSOR (IN RIGHT FRONT OF A/C CONDENSER)
BATTERY
BLK WIRE
BLK/GRY WIRE
BLK/LT GRN WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
DELAY FAST SPEED NORMAL SPEED
DELAY SET
ENGINE BREATHER HEATER (INTAKE ELBOW CRANKCASE BREATHER TUBE)
FLICK
FUSE 15
FUSE 17
FUSE 8
HEADLIGHT RELAY (LEFT FRONT COMPONENT PANEL)
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION SWITCH
INSTRUMENT PACK
LEFT FUSE PANEL (LEFT COMP PANEL)
LEFT HEADLIGHT WASHER HEATER (HEADLIGHT WASHER JET)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/BRN WIRE
LT GRN/GRN WIRE
LT GRN/PPL WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
NCA WIRE
OFF
ORG/ WIRE
RED WIRE
RIGHT FUSE PANEL (RIGHT COMP PANEL)
RUN WIRE
WASH/WIPE 1 4
WASHER FLUID LEVEL
WASHER JET HEATERS
WASHER PUMPS (RIGHT FRONT INNER FENDER)
WASHER RESERVOIR LEVEL SENSOR (BELOW UPPER RADIATOR HOSE)
WHT WIRE
WHT/BLU WIRE
WHT/LT GRN WIRE
WIPER LOGIC MODULE (BEHIND RIGHT COMPONENT PANEL)
WIPER MOTOR UNIT (FRONT PLENUM)
WIPER SWITCH
Go to component -> Wiper/washer circuit -> DELAY FAST SPEED NORMAL SPEED
