Jaguar XJS Series 3 (1990-1996) battery charge indicator Wiring diagram
This page shows the only wiring diagram for the component.battery charge indicator, which is found in the car Jaguar XJS Series 3 (1990-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery charge indicator (1 of 1)
ALTERNATOR
BATTERY (TRUNK)
BATTERY CHARGE INDICATOR
BLK WIRE
BRN WIRE
BRN/BLK WIRE
HOT IN START FUSE 7
INERTIA SWITCH (RIGHT SIDE OF STEERING COLUMN)
INSTRUMENT PACK
NCA WIRE
RIGHT FUSE PANEL (RIGHT COMPONENT PANEL)
RIGHT TERMINAL POST
STARTER MOTOR AND SOLENOID (ENGINE COMPARTMENT)
WHT/PPL WIRE
WHT/RED WIRE
