Jaguar XJR III (2003-2009) climate control panel front electronic module wiring diagram
This page shows the only wiring diagram for the component.climate control panel front electronic module, which is found in the car Jaguar XJR III (2003-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
climate control panel front electronic module wiring diagram (1 of 1)
ADAPTIVE SPEED CONTROL MODULE
AUTOLAMP SENSOR
BRN WIRE
BRN/WHT WIRE
CLIMATE CONTROL MODULE
CLIMATE CONTROL PANEL FRONT ELECTRONIC MODULE
DRIVER DOOR MODULE
FROM FRONT ELECTRONIC MODULE (DIAGRAM 1 OF 6)
FROM REAR ELECTRONIC MODULE (DIAGRAM 1 OF 6)
FRONT ELECTRONIC MODULE
FUSE
FUSE FUSE
GLOVE BOX LAMP)
GLOVE BOX MOTOR
GRN/BLU WIRE
LEFT FRONT FOOTWELL LAMP
LEFT FRONT SIDE MARKER LAMP RIGHT FRONT SIDE MARKER LAMP
LEFT HEADLAMP UNIT OR LEFT HID HEADLAMP UNIT
LEFT TURN SIGNAL REPEATER
LEFT VANITY MIRROR LAMP
ORG/ WIRE
ORG/YEL WIRE
PASSIVE ANTI-THEFT SYSTEM TRANSCEIVER
REAR CLIMATE CONTROL MODULE
REAR ELECTRONIC MODULE
RED/WHT WIRE
RIGHT FRONT FOOTWELL LAMP
RIGHT HEADLAMP UNIT OR RIGHT HID HEADLAMP UNIT
RIGHT TURN SIGNAL REPEATER
RIGHT VANITY MIRROR LAMP
SWITCHED SYSTEM POWER RELAY 1
SWITCHED SYSTEM POWER RELAY 2
TO REAR POWER DISTRIBUTION FUSE BOX (DIAGRAM 4 OF 6)
W/O NAVIGATION
WINDSHIELD WASHER PUMP
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> CLIMATE CONTROL PANEL FRONT ELECTRONIC MODULE
