Jaguar XJR II (1994-2003) Charging circuit

BATTERY (RIGHT SIDE OF TRUNK) BLK WIRE CHARGE WARNING ENGINE COMPARTMENT FUSE BOX (IN LEFT FRONT OF ENGINE COMPARTMENT) FUSE 2 GENERATOR (RIGHT FRONT OF ENGINE COMPARTMENT) GRN WIRE HIGH POWER PROTECTION MODULE (IN LUGGAGE COMPARTMENT, NEXT TO BATTERY) HOT IN RUN, START INSTRUMENT PACK RED WIRE STARTER MOTOR SUPPRESSION MODULE (IN RIGHT FRONT OF ENGINE COMPARTMENT) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE
