Power top/sunroof circuit for Jaguar XJR II (1994-2003)

1 2 3 4 5 6 BATTERY (B+) DATA STREAM GROUND DATA STREAM OPEN SWITCH CLOSE SWITCH 1 2 3 ROOF MOTOR 1 2 ANTENNA SHIELD BRAIDED 13 14 GROUND GROUND 16 8 SCP DATA SCP DATA BATTERY (B+) BLK WIRE BLK/PNK WIRE BLU WIRE BODY PROCESSOR MODULE (BEHIND GLOVE BOX) BRAIDED BRAIDED BRN WIRE BRN/RED WIRE BRN/WHT WIRE CENTER CONSOLE SWITCH PACK CENTRAL LOCKING SWITCH CLOSE COMPUTER DATA LINES SYSTEM FUSE 10 FUSE 17 FUSE 5 FUSE 7 HOT AT ALL TIMES IGNITION SWITCH III OFF KEY FOB ANTENNA LEFT HEELBOARD FUSE BOX (UNDER FRONT OF LEFT REAR SEAT BOTTOM) NCA WIRE OFF ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE RED/WHT WIRE RIGHT HEELBOARD FUSE BOX (UNDER FRONT OF RIGHT REAR SEAT BOTTOM) ROOF MOTOR RUN WIRE SECURITY, LOCKING CONTROL MODULE (BELOW TRUNK FUSE BOX) SLIDING ROOF CONTROL MODULE (IN ROOF CONSOLE) SLIDING ROOF MOTOR (IN ROOF CONSOLE) SLIDING ROOF SWITCH TRUNK FUSE BOX (AT RIGHT SIDE OF TRUNK) VALET SWITCH WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE
