Jaguar XJ X351 (2009-2015) static bending lamp led array wiring diagram
This page shows the only wiring diagram for the component.static bending lamp led array, which is found in the car Jaguar XJ X351 (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
static bending lamp led array wiring diagram (1 of 1)
14 13 15 AFS MOTOR
6 5 7 LEVEL MOTOR CONTROL
BATTERY JUNCTION BOX (LOWER
BATTERY SAVER RELAY
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (LEFT REAR SEAT BACKREST)
COMPUTER DATA LINES SYSTEM
DCM R/L
FUSE FUSE FUSE
FUSE REAR OF LUGGAGE COMPT)
GRY/ORG WIRE
HEADLAMP CONTROL MODULE (RIGHT FRONT PASSENGER COMPT)
HOT AT ALL TIMES
HS CAN NEG HS CAN POS
IGN LH COR LIGHT RH COR LIGHT
LEVEL AFS MOTOR STATIC MOTOR CONTROL BENDING LAMP LED ARRAY LEFT HEADLAMP
LIN R/L
MS CAN NEG
MS CAN POS
PPL/GRN WIRE
PPL/GRY WIRE
PPL/ORG WIRE
RIGHT HEADLAMP
SPLY
STATIC BENDING LAMP LED ARRAY
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Adaptive front lighting circuit -> STATIC BENDING LAMP LED ARRAY
