Tire pressure monitoring circuit for Jaguar XFR I (2009-2011)

16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 RF RTN RF PWR LF RTN LF PWR 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 VBATT BLK WIRE BLU/BRN WIRE BLU/ORG WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (RIGHT KICK PANEL) COMPUTER DATA LINES SYSTEM DATA EXT RF RX FUSE 33 GND MS CAN POS MS CAN NEG GRY/ORG WIRE GRY/VIO WIRE HOT AT ALL TIMES LEFT FRONT INITIATOR (BEHIND LEFT FRONT WHEEL ARCH LINER) LEFT FRONT TIRE SENSOR LEFT REAR INITIATOR (BEHIND LEFT REAR WHEEL ARCH LINER) LEFT REAR TIRE SENSOR REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT) RED WIRE RH RR RTN RH RR PWR LH RR RTN LH RR PWR RIGHT FRONT INITIATOR (BEHIND RIGHT FRONT WHEEL ARCH LINER) RIGHT FRONT TIRE SENSOR RIGHT REAR INITIATOR (BEHIND RIGHT REAR WHEEL ARCH LINER) RIGHT REAR TIRE SENSOR TIRE PRESSURE MONITORING RECEIVER (UNDER REAR OF CENTER CONSOLE) TIRE PRESSURE MONITORING SYSTEM MODULE (UNDER FRONT PASSENGER'S SEAT) VBATT VIGN VIO/BRN WIRE VIO/ORG WIRE YEL WIRE
