Jaguar XFR I (2009-2011) Trunk & fuel door release circuit

3 4 MS CAN POS MS CAN NEG 32 22 LOGIC GND GND 4 5 MS CAN IN NEG MS CAN IN POS AUX SW SIG AUXILIARY LIGHTING SWITCH BLK WIRE BOOT OPEN BOOT RELEASE SW BRN/VIO WIRE CENTRAL JUNCTION BOX INTERNAL ELECTRONICS (RIGHT KICK PANEL) COMPUTER DATA LINES SYSTEM EXTERNAL TRUNK RELEASE SWITCH FUEL FLAP FUEL FLAP MTR FUEL FLAP RELEASE MOTOR (RIGHT SIDE OF LUGGAGE COMPT) FUSE 33 FUSE 34 GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER INTERNAL ELECTRONICS KEYLESS VEHICLE MODULE (LEFT SIDE OF LUGGAGE COMPT) LOGIC PWR LUGGAGE COMPARTMENT LID LATCH (CENTER REAR OF TRUNK LID) LUGGAGE COMPARTMENT LID RELEASE SWITCH, NUMBER PLATE LAMP MS CAN + REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT) SOFT TOUCH TRUNK MTR OPEN TRUNK RELEASE SWITCH V BATT VIO/ORG WIRE WHT WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/RED WIRE
