Jaguar XFR I (2009-2011) Shift interlock circuit

APPLY SW 1 RELEASE SW 1 HALL SUPPLY HALL SENS GND MOTOR POS BLK WIRE BLU/GRY WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX FUSE 22 (RIGHT KICK PANEL) COMPUTER DATA LINES SYSTEM EPB APPLY 1 EPB APPLY 2 EPB REL 1 EPB REL 2 EPB RTN FOOT BRAKE SWITCH FUSE 2 FUSE 21 GND RELEASE SW 2 GRN/ORG WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HS CAN NEG HS CAN POS SW RTN BRAKE PEDAL SW IGN HALL SIG LOGIC BATT INTERNAL ELECTRONICS MOTOR NEG PARKING BRAKE ACTUATOR (ON REAR SUSPENSION SUBFRAME) PARKING BRAKE MODULE (RIGHT REAR OF LUGGAGE COMPT) REAR JUNCTION BOX STOP LAMP SWITCH (TOP OF BRAKE PEDAL BRACKET ASSEMBLY) TRANSMISSION SHIFT MODULE (UNDER CENTER CONSOLE) VIO/BRN WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/RED WIRE
