Headlamps & front fog lamps circuit, without high intensity discharge for Jaguar XFR I (2009-2011)

12 13 MS CAN + MS CAN - 20 2 RH DIP BEAM RH MAIN BEAM 22 32 GND GND 4 5 28 11 15 6 MS CAN - MS CAN + FOG SW HDLP SW FLASH SW STALK SW RET 9 1 MS CAN - MS CAN + AUTOLAMP AUXILIARY LIGHTING SWITCH BATTERY JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT) BLK WIRE BLU/GRN WIRE BRN/BLU WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (RIGHT KICK PANEL) COMPUTER DATA LINES SYSTEM DIP BEAM DIP BEAM LAMP FUSE GRN/BRN WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LEFT HEADLAMP LEFT REAR FOG LAMP LH DIP BEAM LH MAIN BEAM MAIN BEAM MAIN BEAM LAMP OFF REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT) RED WIRE RIGHT HEADLAMP RIGHT REAR FOG LAMP RR FOG LP CTRL SIDE LIGHT STEERING COLUMN LIGHTING SWITCH VIO/ORG WIRE WHT/BLU WIRE YEL/BLU WIRE
