Fibre optic network circuit for Jaguar XFR I (2009-2011)

1 2 MOST RX MOST TX 2 1 MOST TX MOST RX INFORMATION, ENTERTAINMENT CONTROL MODULE INTEGRATED AUDIO MODULE MOST DIAGNOSTIC CONNECTOR (LEFT KICK PANEL) MOST RX MOST TX MOST TX MOST RX ORG/ WIRE PORTABLE AUDIO INTERFACE MODULE TELEPHONE MODULE (UNDER DRIVER'S SEAT) TOUCH SCREEN DISPLAY W/ PORTABLE AUDIO W/ PORTABLE AUDIO, W/ TELEPHONE W/ TELEPHONE W/ TRUNK MOST MODELS W/O PORTABLE AUDIO W/O TRUNK MOST MODELS

1 2 MOST RX MOST TX 2 1 MOST TX MOST RX AUDIO AMPLIFIER DIGITAL AUDIO BROAD- CASTING OR SATELLITE DIGITAL AUDIO RECOVER SYSTEM DIGITAL AUDIO BROADCASTING OR SATELLITE DIGITAL AUDIO RECOVER SYSTEM LUGGAGE COMPT) MOST RX MOST TX NAVIGATION SYSTEM MODULE (LEFT SIDE OF NAVIGATION SYSTEM MODULE (LEFT SIDE OF LUGGAGE COMPT) ORG/ WIRE TELEVISION TELEVISION NAVIGATION SYSTEM MODULE (LEFT SIDE OF LUGGAGE COMPT) W/ AMP W/ DAB OR SDARS W/ DAB OR SDARS, AMP W/ DAB OR SDARS, MMM W/ DAB OR SDARS, MMM, AMP W/ MMM W/ MMM, AMP W/ TV W/ TV, AMP W/ TV, DAB OR SDARS W/ TV, DAB OR SDARS, AMP W/ TV, DAB OR SDARS, MMM W/ TV, MMM, AMP W/ TV,DAB OR SDARS, MMM, AMP
