Tire pressure monitoring circuit for Jaguar XF II (2015-2020)
Tire pressure monitoring circuit
BLK/YEL WIRE
COMPUTER DATA LINES SYSTEM
GRN/ORG WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HS CAN H (PT)
HS CAN L (PT)
LEFT FRONT TIRE SENSOR
LEFT REAR TIRE SENSOR
NCA WIRE
PASSENGER JUNCTION BOX
PPL/RED WIRE
RIGHT FRONT TIRE SENSOR
RIGHT REAR TIRE SENSOR
SPARE TIRE SENSOR
TIRE PRESSURE MONITORING SYSTEM MODULE
