Trunk & fuel door release circuit for Jaguar XF II (2015-2020)
Trunk & fuel door release circuit
AJAR SWITCH
AUXILIARY LIGHTING SWITCH
BATTERY JUNCTION BOX
BCM-GWM ASSEMBLY
BLK WIRE
BOOT AJAR
BRN WIRE
EXT BOOT REL SW
EXTERIOR TAILGATE
FUEL FLAP LOCK
FUEL FLAP RELEASE MOTOR
FUEL FLAP UNLOCK
FUSIBLE LINK 6
HOT AT ALL TIMES
INTERIOR RELEASE TAILGATE SWITCH
KEYLESS VEHICLE MODULE
LIGHTING STALK GND
LUGGAGE COMPARTMENT CENTRAL DOOR LOCKING MOTOR
LUGGAGE COMPARTMENT RELEASE SWITCH
MAIN GND
RELEASE SWITCH
RESISTIVE LADDER SWITCH 1
TAILGATE RELEASE
TAILGATE)
W/ KEYLESS ENTRY
W/ LDW W/O LDW
WHT/BRN WIRE
