Power top/sunroof circuit for Jaguar XF II (2015-2020)
Power top/sunroof circuit
BLIND CLOSE
BLIND OPEN
BLK WIRE
BLU/WHT WIRE
BRN/GRN WIRE
FRONT OVERHEAD CONSOLE
FUSE 23
GRN/WHT WIRE
GRY/BRN WIRE
GRY/PPL WIRE
HOT AT ALL TIMES
HOT W/ COMFORT RELAY ENERGIZED
IGN
LIGHTING 1
LIN 3
O DEMAND INTERIOR
PASSENGER JUNCTION BOX
PPL/BRN WIRE
REAR JUNCTION BOX
REAR SCREEN SUNBLIND
ROOF BLIND CLOSE
ROOF BLIND OPEN
ROOF OPENING PANEL CONTROL MODULE
SUN BLIND MOTOR
SUNROOF FUSE
SUNROOF OPEN (+)
SUNROOF OPEN SUNROOF CLOSE
SUNROOF OPEN/CLOSE
SUNROOF TILT/CLOSE
WHT/RED WIRE
YEL WIRE
YEL/ORG WIRE
