Horn circuit for Jaguar XF II (2015-2020)
Horn circuit
BCM-GWM ASSEMBLY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CLOCK- SPRING
GND IN
GRY WIRE
HORN CONTROL
HORN IN
HORN RELAY
HORN SWITCH
HORNS FUSE
HOT AT ALL TIMES
LEFT HORN
LEFT STEERING WHEEL SWITCHPACK
LIN
LIN 1
LOGIC GND
NCA WIRE
PASSENGER JUNCTION BOX
PPL/GRN WIRE
PPL/RED WIRE
RED WIRE
RIGHT HORN
RIGHT STEERING WHEEL SWITCHPACK
STEERING WHEEL MODULE
SWM FUSE
UNDER BONNET FUSE BOX
V BATT
WHT WIRE
YEL/PPL WIRE
YEL/RED WIRE
