Car Wiring Diagrams for Rear defogger circuit for Jaguar XF II (2015-2020)

BCM-GWM ASSEMBLY BLU WIRE BRN WIRE BRN/BLU WIRE CLIMATE CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSIBLE LINK 4 GRY/PPL WIRE GWM HS CAN H GWM HS CAN L HOT AT ALL TIMES HS CAN-H HS CAN-L NCA WIRE PPL/GRN WIRE REAR HEATED SCREEN CONTROL REAR HEATED SCREEN RELAY REAR JUNCTION BOX REAR WINDOW HEATED ELEMENT RED WIRE RF FILTER
