Jaguar XF II (2015-2020) left outer register motor Wiring diagrams
This page contains all the electrical diagrams for the component. left outer register motor, in which he is found in the car Jaguar XF II (2015-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left outer register motor (1 of 2)
A/C CLUTCH CTRL
BATTERY JUNCTION BOX
BCM-GWM ASSEMBLY (ON PASSENGER JUNCTION BOX)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLWR MTR RLY CTRL
BRN WIRE
BRN/GRN WIRE
BRN/PPL WIRE
CHANGEOVER VALVE
CLIMATE CONTROL MODULE
CLUTCH PWR IN
COMP SOL + PPL COMP SOL -
COMPUTER DATA LINES SYSTEM
FB HTR DIV VLV
FL FACE DUCT SENS
FR FACE DUCT SENS
FR FOOT DUCT SENS
FUSE 15
FUSIBLE LINK 6
GRN WIRE
GRN/BLU WIRE
GRN/PPL WIRE
GRY WIRE
GRY/BRN WIRE
GRY/PPL WIRE
GRY/YEL WIRE
GWM HS CAN H (CH)
GWM HS CAN L (CH)
HOT AT ALL TIMES
HOT W/ GRAPHICAL RELAY 2 ENERGIZED
HS CAN-H
HS CAN-L
IN CAR TEMP SENS
LEFT OUTER REGISTER MOTOR
LH SOLAR SENS
LIGHTING 1
LIN 1
LIN 1 (HVAC) FL FOOT DUCT SENS
LIN 2 PWR
LIN 4
LIN IN
LIN OUT
MTR GND
MTR PWR
O DEMAND INTERIOR
O IGNITION 5
PPL
PPL/GRN WIRE
PPL/GRY WIRE
PPL/ORG WIRE
PPL/RED WIRE
PPL/WHT WIRE
PRESS SENS
PTC HTR 2 RLY CTRL
PTC HTR RLY 1 CTRL
PWR
QUIESCENT CURRENT CONTROL MODULE
REAR BLOWER FUSIBLE LINK
REAR BLOWER RELAY
REAR BLWR RLY CTRL
REAR CLIMATE CONTROL PANEL
RH SOLAR SENS
RIGHT OUTER REGISTER MOTOR
RL FACE DUCT SENS
RL FOOT DUCT SENS
RR FACE DUCT SENS
RR FOOT DUCT SENS
SENS GND (VEH)
TEMPERATURE/ HUMIDITY SENSOR
UNDER BONNET JUNCTION BOX
VBATT
VBATT 1
W/ FRONT/REAR AIR CONDITIONING
WHT/BRN WIRE
WHT/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Automatic a/c circuit (1 of 6) -> LEFT OUTER REGISTER MOTOR
Wiring diagram left outer register motor (2 of 2)
ALL SURFACE PROGRESS CONTROL SWITCH
AUDIO HEAD UNIT
AUDIO-VIDEO INPUT/OUTPUT PANEL
BCM-GWM ASSEMBLY
BLK WIRE
BLK/GRN WIRE
BLK/PPL WIRE
BLK/WHT WIRE
BLU WIRE
CENTER INSTRUMENT PANEL ILLUMINATION
CLIMATE CONTROL MODULE
CLOCK- SPRING
DIAGNOSTIC CONNECTOR
EMERGENCY RESPONSE CONTROL MODULE
FORWARD MOUNTED LUGGAGE COMPARTMENT LAMP
GLOVE BOX SWITCH
GRN WIRE
HEAD-UP DISPLAY CONTROL MODULE
HEAD-UP DISPLAY COOLING FAN
HEAD-UP DISPLAY COOLING FAN MODULE
HIGH MOUNTED STOP LAMP
IMMOBILIZER ANTENNA UNIT
INSTRUMENT CLUSTER
INTEGRATED CLIMATE CONTROL MODULE, SWITCHPACK
LEFT CONSOLE ILLUMINATION
LEFT FRONT FOOTWELL LAMP
LEFT HORN
LEFT OUTER REGISTER MOTOR
ORG/BLU WIRE
PASSENGER SIDE INSTRUMENT PANEL ILLUMINATION
PPL
REAR PORTABLE DEVICE INTERFACE PANEL
REARWARD MOUNTED LUGGAGE COMPARTMENT LAMP
RIGHT CONSOLE ILLUMINATION
RIGHT FRONT FOOTWELL LAMP
RIGHT HORN
RIGHT OUTER REGISTER MOTOR
STEERING WHEEL HEATER
STEERING WHEEL MODULE
TOUCH SCREEN SWITCHPACK
TRANSMISSION CONTROL SWITCH
W/ IN CONTROL APPS W/O IN CONTROL APPS
Go to component -> Ground distribution circuit (2 of 6) -> LEFT OUTER REGISTER MOTOR
