Car Wiring Diagrams for Heated seats circuit for Jaguar XF I facelift (2011-2015)

BLK WIRE BLU/ORG WIRE CENTRAL JUNCTION BOX (RIGHT KICK PANEL) COMPUTER DATA LINES SYSTEM CUSHION HEATERS CUSHION HEATERS DRIVER SEAT CUSHION HEATER DRIVER SEAT BACKREST HEATER GREF GRY/ORG WIRE HOT AT ALL TIMES BATTERY JUNCTION BOX FUSE (RIGHT SIDE OF LUGGAGE COMPT) MS CAN + PASSENGER SEAT BACKREST HEATER PASSENGER SEAT CUSHION HEATER PPL PPL/GRN WIRE PPL/ORG WIRE RED WIRE THERMAL 2 1 SENSOR THERMAL SENSOR WHT/ORG WIRE YEL/GRN WIRE YEL/PPL WIRE
