Driver"s memory seat circuit, with head restraints for Jaguar XF I facelift (2011-2015)

BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/RED WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/PPL WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (RIGHT KICK PANEL) DEFLATE LOWER CELL DEFLATE UPPER CELL DRIVER LUMBAR PUMP DRIVER SEAT MEMORY SWITCH DRIVER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER SEAT SWITCH PACK FUSE 20 FUSE 3 FUSE 4 GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRY WIRE GRY/ORG WIRE GRY/PPL WIRE HEADREST SENS SLIDE MOTOR SENS HGT/SLIDE/EXT MTR HALL GND EXTEND MOTOR SENS HOT AT ALL TIMES ILLUM INFLATE LOGIC FEED MEMORY POWER FEED 1 POWER GND 1 POWER GND 2 LOGIC GND POWER FEED 2 PPL/GRN WIRE SET- SOLENOID LUMBAR PUMP SQUAB MOTOR SENS TILT MOTOR SENS HEIGHT MOTOR SENS STATUS STATUS LED TILT/SQUAB/HREST MTR HALL GND WHT/GRN WIRE YEL WIRE YEL/PPL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 HEADREST UP CUSHION RETRACT BLK WIRE BLU/GRN WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DEFLATE DRIVER HEAD RESTRAINT MOTOR (IN DRIVER'S DRIVER SEAT BACKREST RECLINE MOTOR (UNDER DRIVER'S SEAT) DRIVER SEAT BOLSTER SOLENOID DRIVER SEAT CUSHION EXTEND MOTOR (UNDER DRIVER'S SEAT) DRIVER SEAT FORWARD REARWARD MOTOR DRIVER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER SEAT TILT MOTOR (UNDER DRIVER'S SEAT) DRIVERS SEAT HEIGHT MOTOR (UNDER DRIVER'S SEAT) GND 2 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE INFLATE LIN MS CAN OUT POS MS CAN OUT NEG PPL PPL/GRN WIRE PPL/GRY WIRE PPL/ORG WIRE SLIDE MOTOR FORWARD UPPER SEAT BACK) WHT WIRE YEL WIRE YEL/ORG WIRE YEL/PPL WIRE
