Jaguar XF I facelift (2011-2015) uhego rly ign ign engine ctrl sply ctrl Wiring diagram
This page shows the only wiring diagram for the component.uhego rly ign ign engine ctrl sply ctrl, which is found in the car Jaguar XF I facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram uhego rly ign ign engine ctrl sply ctrl (1 of 1)
ASSY RELAY
BLK WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRAKE PEDAL SWITCH EXTERIOR LIGHTS SYSTEM
CENTRAL JUNCTION BOX (RIGHT
COMPUTER DATA LINES SYSTEM
CRUISE DEACTIVATION SWITCH
EMS CRANK EWU KICK PANEL)
FOOT BRAKE SWITCH
FPDM SUPPLY
FUEL SENS A
FUEL SENS B
FUEL SENS RTN
FUSE 15
FUSE 30
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/PPL WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/PPL WIRE
HEGO RELAY (FULL ISO)
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE ASSY FUSE
LEAK DETECTION UNIT (UNDER LEFT REAR OF VEHICLE)
MS CAN NEG
MS CAN POS
ORG/ WIRE
PPL
PPL PPL
PPL/BRN WIRE
PPL/ORG WIRE
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
SYSTEM GND
UHEGO RLY IGN IGN ENGINE CTRL SPLY CTRL
WHT/ORG WIRE
WHT/RED WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/PPL WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo (5 of 6) -> UHEGO RLY IGN IGN ENGINE CTRL SPLY CTRL
