Jaguar XF I facelift (2011-2015) thermal sensor wiring diagram
This page shows the only wiring diagram for the component.thermal sensor, which is found in the car Jaguar XF I facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
thermal sensor wiring diagram (1 of 1)
BLK WIRE
BLU/ORG WIRE
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
COMPUTER DATA LINES SYSTEM
CUSHION HEATERS
CUSHION HEATERS DRIVER SEAT CUSHION HEATER
DRIVER SEAT BACKREST HEATER
GREF
GRY/ORG WIRE
HOT AT ALL TIMES BATTERY JUNCTION BOX FUSE (RIGHT SIDE OF LUGGAGE COMPT)
MS CAN +
PASSENGER SEAT BACKREST HEATER
PASSENGER SEAT CUSHION HEATER
PPL
PPL/GRN WIRE
PPL/ORG WIRE
RED WIRE
THERMAL 2 1 SENSOR
THERMAL SENSOR
WHT/ORG WIRE
YEL/GRN WIRE
YEL/PPL WIRE
Go to component -> Heated seats circuit -> THERMAL SENSOR
