Jaguar XF I facelift (2011-2015) red Wiring diagrams
This page contains all the electrical diagrams for the component. red, in which he is found in the car Jaguar XF I facelift (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram red (31 of 76)
ALERT LED
BATTERY JUNCTION BOX
BLK WIRE
BLU WIRE
BLU/BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (BEHIND DRIVER DOOR TRIM)
DRIVER SIDE DOOR MIRROR
FUSE (RIGHT SIDE OF LUGGAGE COMPT)
GRY/ORG WIRE
HOT AT ALL TIMES
IGN SPLY
KL 31
LEFT BLIND SPOT MONITORING MODULE (BEHIND LEFT SIDE OF REAR BUMPER)
MIRR GND
MIRROR
MS CAN NEG
MS CAN POS
PARK AID
PASSENGER DOOR MODULE (BEHIND PASSENGER DOOR TRIM)
PASSENGER SIDE DOOR MIRROR
PPL/BRN WIRE
PPL/ORG WIRE
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RIGHT BLIND SPOT MONITORING MODULE (BEHIND RIGHT SIDE OF REAR BUMPER)
STATUS LED
SYSTEM GND
SYSTEM STATUS LED
WARNING ALERT LED
WHT/GRN WIRE
YEL/GRN WIRE
Go to component -> Blind spot monitoring circuit -> RED WIRE
Wiring diagram red (32 of 76)
15 3 23 12 MS CAN - MS CAN + MIRROR GND PUDDLE LIGHT
2 15 B+ GREF
BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT ACCESSORY
FUSE FUSE
GLOVE BOX GLOVE BOX LATCH ILLUMINATION SWITCH LAMP
GLOVE COMPARTMENT CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
GRN/ORG WIRE
GRY/ORG WIRE
GRY/PPL WIRE
HOT AT ALL TIMES REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
LEFT
LEFT FRONT FOOTWELL LAMP
LEFT SUN- VISOR LAMP
LOADSPACE TORCH PWR BOOT LAMPS
LUGGAGE COMPARTMENT LAMP (W/ SPORT BRAKE)
MS MS FADE CAN - CAN + GND CTRL
NCA WIRE
PASSENGER SIDE DOOR MIRROR
PASSENGER SIDE DOOR MODULE (BEHIND PASSENGER DOOR TRIM)
PPL/GRN WIRE
PPL/ORG WIRE
PPL/RED WIRE
REAR INTERIOR LAMP
RED WIRE
RIGHT
RIGHT FRONT FOOTWELL LAMP
RIGHT SUN- VISOR LAMP
TAILGATE LAMPS POWER
W/ SPORT BRAKE
W/O SPORT BRAKE
W/O SPORT BRAKE W/ SPORT BRAKE
W/O W/ SPORT SPORT BRAKE BRAKE
WHT WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RED WIRE
Wiring diagram red (33 of 76)
3 9 4 5 AUX SW RTN DIMMER LEVEL MS CAN - MS CAN +
4 5 11 15 6 MS CAN IN NEG MS CAN IN POS HEADLAMP SW BEAM FLASH SW STALK SW RET
AUTOLAMP
AUXILIARY LIGHTING SWITCH
BATTERY JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
BEAM
BLK WIRE
BLU/WHT WIRE
CENTER INSTRUMENT PANEL SWITCH PACK
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM (RIGHT KICK PANEL)
DIM IND
DIMMER FEED
DIP BEAM
DRIVER DOOR PASSENGER DOOR AMBIENT LED AMBIENT LED
FA IND
FOG IND
FRONT CIGAR LIGHTER
FUSE
GRN/BRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/PPL WIRE
GRY/YEL WIRE
HALO ILLUMI- NATION
HAZARD ILLUM
HL IND
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTEGRATED CONTROL PANEL
LD IND
LEFT FRONT DOOR SILL LAMP
MAIN
MAIN BEAM
NCA WIRE
OFF
OVERHEAD CONSOLE
PPL/ORG WIRE
PWM FUSE MS ILLUM CAN - CAN + SUPPLY B+ GND
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RIGHT FRONT DOOR SILL LAMP
SIDE LIGHT
STEERING COLUMN LIGHTING SWITCH
SUPPLY
SW RET
TR IND
WHT/BRN WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> RED WIRE
Wiring diagram red (34 of 76)
15 3 MS CAN - MS CAN +
20 18 4 L LIN GND SW ILL
BLK WIRE
BLU/WHT WIRE
CLOCK SPRING (IN STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROLS REMOTE
DOWNSHIFT PADDLE SWITCH
DRIVER DOOR MODULE (IN DRIVER ENTRY DOOR)
DRIVER MEMORY SEAT SWITCH PACK
GRY/BLU WIRE
HEAD
ICE REMOTE SWITCH
ILLUM
L LIN
L LIN SW ILL
LEFT REAR DOOR MODULE (IN LEFT ENTRY DOOR)
LEFT REAR WINDOW SWITCH
MEDIA MUTE
MEM- VOL-
PASSENGER DOOR MODULE (IN PASSENGER ENTRY DOOR)
PASSENGER DOOR SWITCH PACK
PPL/BRN WIRE
RED WIRE
RED/WHT WIRE
RES+
RIGHT REAR DOOR MODULE (IN RIGHT ENTRY DOOR)
RIGHT REAR WINDOW SWITCH
SET-
SW ILL.
UPSHIFT PADDLE SWITCH
Go to component -> Instrument illumination circuit (2 of 2) -> RED WIRE
Wiring diagram red (35 of 76)
1 2 IAM CVBS SIG IAM CVBS GND
1 2 MOST RX MOST TX COMPUTER DATA LINES SYSTEM
1 2 SCR PPL
1 2 SIG SCN
1 2 TV CVBS SIG TV CVBS GND
BLK WIRE
BRN WIRE
BRN/RED WIRE
FUSE
GND 1 STRG WHEEL AUDIO SW
GND 2
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT TV ANTENNA
LVDS IN SCR
NCA WIRE
ORG/ WIRE
PPL
PPL/ORG WIRE
PPL/RED WIRE
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RIGHT TV ANTENNA
RVPA CAMERA CVBS SIG RVPA CAMERA CVBS GND 1 2
SIG CODE E SCN
SPLY 1
SPLY 2
TOUCH- SCREEN
TV ANTENNA
W/ ANALOG
W/ SPORTBRAKE W/O SPORTBRAKE
Go to component -> Navigation circuit, 10 speaker system (1 of 5) -> RED WIRE
Wiring diagram red (36 of 76)
1 2 3 4 5 GND
1 2 3 4 ANTENNA 1 ANTENNA 1 SCR ANTENNA 2 ANTENNA 2 SCR
1 2 3 4 ANTENNA 3 ANTENNA 3 SCR ANTENNA 4 ANTENNA 4 SCR
1 2 3 VBATT GND
1 2 CVBS OUT CVBS GND
1 2 MOST RX MOST TX
4 5 CVBS OUT CVBS GND
6 7 VIDEO NEG VIDEO POS
BLK WIRE
BRN WIRE
BRN/RED WIRE
CLOCK SPRING (IN STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
GRY/YEL WIRE
ICE REMOTE SWITCH
MUTE
NCA WIRE
ORG/ WIRE
PPL
REARVIEW CAMERA (IF EQUIPPED) (RIGHT SIDE OF TRUNK LID)
RED WIRE
RED/WHT WIRE
TELEVISION (TV) CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT)
VBATT
VOL + MEM + MEM - MEDIA
VOL - ICE SIG GND
W/O SPORTBRAKE W/ SPORTBRAKE W/ ANALOG W/ DIGITAL
Go to component -> Navigation circuit, 10 speaker system (2 of 5) -> RED WIRE
Wiring diagram red (37 of 76)
1 2 3 4 5 PPL
1 2 3 4 5 USB POS USB DATA NEG USB DATA POS USB GND USB SHIELD PPL
1 2 AM FM SIG AM FM SCN
1 2 GPS SIG GPS SCN
1 2 MOST RX MOST TX
2 1 CVBS VIDEO SCN CVBS VIDEO SIG
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
DATA
FUSE JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
HOT AT ALL TIMES
INTEGRATED AUDIO MODULE (CENTER OF DASH)
LH NEG
LH POS
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
PORTABLE USER INTERFACE DEVICE
PPL
REAR
RED WIRE
RH NEG
RH POS
SCR 2 1 LVDS SCR LVDS POS LVDS NEG PPL
SHIELD
USB GND
USB POS
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Navigation circuit, 10 speaker system (3 of 5) -> RED WIRE
Wiring diagram red (38 of 76)
AM/FM ANTENNA AMPLIFIER (TOP OF RIGHT "C" PILLAR)
AMP
AUDIO ANTENNA 2
BLK WIRE
BLU WIRE
BRN/RED WIRE
COMPUTER
DAB
DAB TUNER MODULE (IF EQUIPPED)
DATA LINES
GPS
GRN/ORG WIRE
GRY/ORG WIRE
LEFT FRONT DOOR BASS SPEAKER
LEFT FRONT DOOR MID RANGE SPEAKER
LEFT FRONT TWEETER
MOST RX
MOST TX
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
OVERHEAD HANDS FREE CONSOLE MICROPHONE (IF EQUIPPED)
PPL/ORG WIRE
RED WIRE
RIGHT FRONT TWEETER
ROOF POD
SCN
SCR
SIG
SUPPLY
SYSTEM
VBATT
WHT WIRE
WHT/BRN WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Navigation circuit, 10 speaker system (4 of 5) -> RED WIRE
Wiring diagram red (39 of 76)
1 2 IAM CVBS SIG IAM CVBS GND
1 2 MOST RX MOST TX COMPUTER DATA LINES SYSTEM
1 2 SCR PPL
1 2 SIG SCN
1 2 TV CVBS SIG TV CVBS GND
18 19 PPL
BLK WIRE
BRN WIRE
FUSE
GND 1 STRG WHEEL AUDIO SW
GND 2
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT TV ANTENNA
LVDS IN SCR
NCA WIRE
ORG/ WIRE
PPL/ORG WIRE
PPL/RED WIRE
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RIGHT TV ANTENNA
RVPA CAMERA CVBS SIG RVPA CAMERA CVBS GND 1 2
SIG CODE E SCN
SPLY 1
SPLY 2
TOUCH- SCREEN
TV ANTENNA
W/ ANALOG
W/ SPORTBRAKE W/O SPORTBRAKE
Go to component -> Navigation circuit, 12 & 15 speaker systems (1 of 6) -> RED WIRE
Wiring diagram red (40 of 76)
BLK WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
DRIVER SEAT TILT MOTOR (UNDER DRIVER'S SEAT)
FUSE
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LOGIC FEED
PASSENGER HEAD RESTRAINT MOTOR (IN FRONT PASSENGER'S UPPER SEAT BACK)
PASSENGER SEAT CUSHION EXTENSION MOTOR
PASSENGER SEAT FORWARD REARWARD MOTOR
PASSENGER SEAT HEIGHT MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT MODULE
PASSENGER SEAT TILT MOTOR (UNDER FRONT PASSENGER'S SEAT)
POWER FEED 1
POWER GND 1
POWER GND 2 LOGIC GND POWER FEED 2
PPL/GRY WIRE
PPL/ORG WIRE
RED WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/PPL WIRE
YEL/RED WIRE
Go to component -> Passenger"s memory seat circuit (2 of 2) -> RED WIRE
