Jaguar XF I facelift (2011-2015) ppl ecfc Wiring diagram
This page shows the only wiring diagram for the component.ppl ecfc, which is found in the car Jaguar XF I facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ppl ecfc (1 of 1)
12 33 38 62 ECT SENSOR ECT RTN
2.0L TURBO
35 34 1 11 12 1 AMB TEMP AMB TEMP RTN GND 1
41 54 80 79 H CAN - H CAN +
AIR CONDITIONING COMPRESSOR CLUTCH (A/C)
AMBIENT AIR TEMPERATURE SENSOR
BLK WIRE
BLU WIRE
BRN/PPL WIRE
CHARGE AIR COOLER TEMPERATURE SENSOR (EXCEPT 2.0L TURBO)
COMPUTER DATA LINES SYSTEM
CONTROL COMPRESSOR VALVE CLUTCH SOLENOID
COOLING FAN CONTROL UNIT
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR 2
EXCEPT 2.0L TURBO
EXCEPT 2.0L TURBO 2.0L TURBO
FUSE
FUSE 1
FUSE 41
FUSE 44
FUSE 45
GRN WIRE
GRN/BRN WIRE
GRY WIRE
GRY/YEL WIRE
HOT AT ALL TIMES ENGINE JUNCTION BOX (UNDER ENGINE COMPT FUSE BOX)
HOT W/ HIGH CURRENT EMS RELAY ENERGIZED
LEFT DOOR MIRROR ASSEMBLY
NCA WIRE
OP RAD TEMP SENS
PPL
PPL ECFC
RADIATOR OUTLET TEMPERATURE SENSOR (2.0L TURBO)
RED WIRE
RWTS G R ACTS
SC OUTLET TEMP SENS
SPLY 1
TEMP SENS RTN
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/PPL WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Automatic a/c circuit (3 of 3) -> PPL ECFC
