Jaguar XF I facelift (2011-2015) ect rtn Wiring diagram
This page shows the only wiring diagram for the component.ect rtn, which is found in the car Jaguar XF I facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ect rtn (1 of 1)
2.0L TURBO
54 1 ECFC GND 1
8 1 PPL
BLK WIRE
BLU WIRE
CHARGE AIR COOLER TEMPERATURE SENSOR (EXCEPT 2.0L TURBO)
COMPUTER DATA LINES SYSTEM
COOLING FAN CONTROL UNIT
ECT RTN
ECT SENSOR
ENGINE CONTROL MODULE (ECM) (LEFT REAR OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR 2
EXCEPT 2.0L TURBO
EXCEPT 2.0L TURBO 2.0L TURBO
FUSE
FUSE 1
FUSE 41
FUSE 44
FUSE 45
GREF TEMP SENS RTN
GRN WIRE
GRN/BRN WIRE
GRY/YEL WIRE
H CAN+
HOT AT ALL TIMES ENGINE JUNCTION BOX (UNDER ENGINE COMPT FUSE BOX)
HOT W/ HIGH CURRENT EMS RELAY ENERGIZED
NCA WIRE
OP RAD TEMP SENS
PPL
RADIATOR OUTLET TEMPERATURE SENSOR (2.0L TURBO)
RED WIRE
RWTS G R ACTS
SC OUTLET TEMP SENS
SPLY 1
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/PPL WIRE
YEL WIRE
Go to component -> Cooling fan circuit -> ECT RTN
