Jaguar XF I facelift (2011-2015) central junction box Wiring diagram
This page shows the only wiring diagram for the component.central junction box, which is found in the car Jaguar XF I facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central junction box (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 RH TAIL LAMP
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 LH TAIL LAMP
9 10 11 12 13 BATT SUPPLY ACCESSORY SUPPLY GND 2
ACC PWR
BATT PWR
BATT SUPPLY 1
BATT SUPPLY 2
BATTERY JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLU WIRE
BLU/GRY WIRE
BLU/PNK WIRE
BLU/WHT WIRE
BRAKE LAMP
BRN WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
FUSE 18
FUSE 28
FUSE FUSE
GND 3
GRN WIRE
GRN/RED WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LH INDICATOR
LIN
MS CAN IN NEG
MS CAN IN POS
POWER
PPL/ORG WIRE
PPL/WHT WIRE
REAR FOG LAMP
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
REVERSE LAMPS
RH INDICATOR
ROAD PRICING CONNECTOR
SYSTEM GND
TRAILER ECU (W/ SPORT BRAKE)
TRAILER PICK-UP
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Trailer tow circuit -> CENTRAL JUNCTION BOX
