Jaguar XF I (2007-2011) reverse lamp ctrl Wiring diagram
This page shows the only wiring diagram for the component.reverse lamp ctrl, which is found in the car Jaguar XF I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reverse lamp ctrl (1 of 1)
5 6 HS CAN + HS CAN -
BATTERY JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LEFT TAIL LAMP UNIT
MS MS CAN CAN
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
REVERSE LAMP
REVERSE LAMP CTRL
RIGHT TAIL LAMP UNIT
TRANSMISSION SHIFT MODULE (UNDER CENTER CONSOLE)
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
Go to component -> Backup lamps circuit -> REVERSE LAMP CTRL
