Jaguar XF I (2007-2011) rear window heater element Wiring diagrams
This page contains all the electrical diagrams for the component. rear window heater element, in which he is found in the car Jaguar XF I (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
rear window heater element wiring diagram (1 of 2)
BLK WIRE
CENTER INSTRUMENT PANEL SWITCH PACK
CENTRAL JUNCTION BOX
DRIVE SEAT TRACK SENSOR
DRIVER DOOR HANDLE
DRIVER DOOR LATCH MODULE
DRIVER LUMBAR PUMP
DRIVER SEAT MODULE
DRIVER SEAT SWITCH PACK
DRIVER WINDOW MIRROR SWITCH PACK
FRONT BLOWER MOTOR CONTROL MODULE
FRONT CIGAR LIGHTER
INFORMATION, ENTERTAINMENT CONTROL MODULE
INTEGRATED CONTROL PANEL
LEFT FRONT DRIVER DOOR DOOR HANDLE MODULE LED
NCA WIRE
OVERHEAD CONSOLE
PASSENGER DOOR MODULE
PASSENGER LUMBAR PUMP
PASSENGER SEAT SWITCH PACK
REAR WINDOW HEATER ELEMENT
RIGHT FRONT DOOR HANDLE LED
STARTER MOTOR
TOUCH SCREEN DISPLAY
W/ 2 WAY LUMBAR W/ 16 WAY DRIVER'S SEAT MOVEMENT
W/ 2 WAY LUMBAR, PROGRAMMABLE DRIVERS SEAT
W/ PROGRAMMABLE DRIVERS SEAT
W/ PROGRAMMABLE DRIVERS SEAT W/O PROGRAMMABLE DRIVERS SEAT
W/O W/ KEYLESS KEYLESS ENTRY ENTRY
Go to component -> Ground distribution circuit (2 of 3) -> REAR WINDOW HEATER ELEMENT
rear window heater element wiring diagram (2 of 2)
15 3 10 23 C- C+ MIRR HTR MIRR GND
2 13 B+ GND
BLK WIRE
BLU WIRE
BRN WIRE
C+ C- MIRR HTR MIRR GND
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MIRROR (IN MIRROR)
DRIVER DOOR MODULE (BEHIND DRIVER DOOR TRIM)
FUSE 30
FUSE 31
FUSE 7
GRN WIRE
HOT AT ALL TIMES
NCA WIRE
PASSENGER DOOR MIRROR (IN MIRROR)
PASSENGER DOOR MODULE (BEHIND PASSENGER DOOR TRIM)
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
REAR SCREEN HEATED RELAY
REAR WINDOW HEATER ELEMENT
RED WIRE
RF FILTER WAVE TRAP
WHT WIRE
Go to component -> Rear defogger & heated mirrors circuit -> REAR WINDOW HEATER ELEMENT
