Jaguar XF I (2007-2011) internal electronics fuse op Wiring diagram
This page shows the only wiring diagram for the component.internal electronics fuse op, which is found in the car Jaguar XF I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram internal electronics fuse op (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 +B
AIR INTAKE +
AIR INTAKE FBACK
B+ SPLY CAN - CAN +
BLK WIRE
BLOWER CTRL
BLOWER FBACK
BLOWER MOTOR RELAY
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN IN - PRESSURE SENS RH SOLAR SENS LH SOLAR SENS
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
CLIMATE CONTROL MODULE (TOP OF RIGHT KICK PANEL)
COMP SOL + COMP SOL - CAN IN + CAN OUT + CAN OUT - NOX IN HC IN IN CAR TEMP
COMPUTER DATA LINES SYSTEM
EVAP SENS
FEET AIR DISTRIBUTION MOTOR (BEHIND CENTER OF DASH)
FUSE
GND ASPIRATOR DIAG
GREF SENS GND
GRN/BLU WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HUMIDITY SENS
INTERNAL ELECTRONICS B+
INTERNAL ELECTRONICS FUSE OP
LEFT MODE AIR MIX MOTOR (ON LEFT SIDE OF HVAC)
LIN
LIN GND HVAC SENS GND
LIN PWR 2
NCA WIRE
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RIGHT MODE AIR MIX MOTOR (ON RIGHT SIDE OF HVAC)
SCREEN AIR DISTRIBUTION DOOR MOTOR (BEHIND CENTER OF DASH)
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit (1 of 2) -> INTERNAL ELECTRONICS FUSE OP
