Jaguar XF I (2007-2011) auxiliary lighting switch Wiring diagrams
This page contains all the electrical diagrams for the component. auxiliary lighting switch, in which he is found in the car Jaguar XF I (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram auxiliary lighting switch (1 of 5)
12 13 MS CAN + MS CAN -
20 2 RH DIP BEAM RH MAIN BEAM
22 32 GND GND
4 5 28 11 15 6 MS CAN - MS CAN + FOG SW HEAD LP SW FLASH SW STALK SW RET
7 20 LH MAIN BEAM RH SBL CTRL
9 1 MS CAN - MS CAN +
AUTOLAMP
AUXILIARY LIGHTING SWITCH
BATTERY JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DIP BEAM
FRONT
GRN/BRN WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HID DIP BEAM
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT HEADLAMP
LEFT REAR FOG LAMP
LH DIP BEAM
LH SBL CTRL
MAIN BEAM
OFF
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RIGHT HEADLAMP
RIGHT REAR FOG LAMP
RR FOG LP CTRL
SIDE LIGHT
STATIC BENDING LAMP
STEERING COLUMN LIGHTING SWITCH
VIO/ORG WIRE
WHT/BLU WIRE
XENON BALLAST
YEL/BLU WIRE
Go to component -> Headlamps & front fog lamps circuit, with high intensity discharge -> AUXILIARY LIGHTING SWITCH
Wiring diagram auxiliary lighting switch (2 of 5)
12 13 MS CAN + MS CAN -
20 2 RH DIP BEAM RH MAIN BEAM
22 32 GND GND
4 5 28 11 15 6 MS CAN - MS CAN + FOG SW HEAD LP SW FLASH SW STALK SW RET
9 1 MS CAN - MS CAN +
AUTOLAMP
AUXILIARY LIGHTING SWITCH
BATTERY JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DIP BEAM
DIP BEAM LAMP
FRONT
GRN/BRN WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LEFT HEADLAMP
LEFT REAR FOG LAMP
LH DIP BEAM
LH MAIN BEAM
MAIN BEAM
MAIN BEAM LAMP
OFF
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
RED WIRE
RIGHT HEADLAMP
RIGHT REAR FOG LAMP
RR FOG LP CTRL
SIDE LIGHT
STEERING COLUMN LIGHTING SWITCH
VIO/ORG WIRE
WHT/BLU WIRE
YEL/BLU WIRE
Go to component -> Headlamps & front fog lamps circuit, without high intensity discharge -> AUXILIARY LIGHTING SWITCH
Wiring diagram auxiliary lighting switch (3 of 5)
15 3 MS CAN - MS CAN +
20 18 4 L LIN GND SW ILL
AUX SW RTN DIMMER LEVEL MS CAN - MS CAN +
AUXILIARY LIGHTING SWITCH
BATTERY JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLU/WHT WIRE
CENTER INSTRUMENT PANEL SWITCH PACK
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
CLOCK SPRING (IN STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROLS REMOTE
DIMMER FEED
DOWNSHIFT PADDLE SWITCH
DRIVER DOOR MODULE (BEHIND DRIVER DOOR TRIM)
DRIVER MEMORY SEAT SWITCH
FRONT CIGAR LIGHTER
GRY/BLU WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HALO ILLUMI- NATION
HEAD
HOT AT ALL TIMES
ICE REMOTE SWITCH
ILLUM
INSTRUMENT CLUSTER
L LIN
L LIN SW ILL
LEFT FRONT DOOR HANDLE LED
LEFT REAR DOOR MODULE (BEHIND LEFT REAR DOOR TRIM)
LEFT REAR WINDOW SWITCH
MEDIA MUTE
MEM
MEM- VOL-
OVERHEAD CONSOLE
PASSENGER DOOR MODULE (BEHIND PASSENGER DOOR TRIM)
PASSENGER DOOR SWITCH PACK
PWM MS ILLUM CAN - CAN + SUPPLY B+ GND
RED WIRE
RED/WHT WIRE
RES+
RIGHT FRONT DOOR HANDLE LED
RIGHT REAR DOOR MODULE (BEHIND RIGHT REAR DOOR TRIM)
RIGHT REAR WINDOW SWITCH
SET-
SW ILL.
UPSHIFT PADDLE SWITCH
VIO/BRN WIRE
VIO/ORG WIRE
VOL (-)
WHT/BRN WIRE
Go to component -> Instrument illumination circuit -> AUXILIARY LIGHTING SWITCH
Wiring diagram auxiliary lighting switch (4 of 5)
ABS MODULE
AUXILIARY LIGHTING SWITCH
BLK WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/RED WIRE
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
CIGAR LIGHTER RELAY
COOLING FAN CONTROL UNIT
ENGINE JUNCTION BOX (UNDER ENGINE COMPT FUSE BOX)
ENGINE TRANSMISSION TCM, CONTROL SHIFT CONTROL MODULE MODULE VALVE BODY
FROM CENTRAL JUNCTION BOX (DIAGRAM 3 OF 4)
FROM FUSE 12 (DIAGRAM 3 OF 4)
FROM FUSE 17 (DIAGRAM 4 OF 4)
FROM FUSE 24 (DIAGRAM 4 OF 4)
FROM FUSE 37 (DIAGRAM 3 OF 4)
FROM FUSE 5 (DIAGRAM 4 OF 4)
FRONT CIGAR LIGHTER
FUSE 13 WIPER HI/LOW RELAY
FUSE 14 STARTER MOTOR RELAY
FUSE 15
FUSE 16 RIGHT FRONT SCREEN HEATER RELAY
FUSE 17
FUSE 22 FUSE 21 FUSE 20
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 39
FUSE 5
FUSE 6 POWER WASH PUMP RELAY
GLOVE COMPARTMENT CONTROL MODULE
GLOVE COMPARTMENT LAMP
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLAMP LEFT CONTROL HEADLAMP MODULE
HEGO RELAY
HORN RELAY
INTERNAL ELECTRONICS
LEFT FRONT FOOTWELL LAMP
LEFT FRONT SCREEN HEATER RELAY
LEFT SUN- VISOR LAMP
OVERHEAD CONSOLE
REAR INTERIOR LAMP
RED WIRE
RIGHT FRONT FOOTWELL LAMP
RIGHT HEADLAMP
RIGHT SUN- VISOR LAMP
SPEED CONTROL MODULE
SPEED CONTROL SENSOR
TO FUSE 14 (DIAGRAM 4 OF 4)
TO FUSE 26 (DIAGRAM 4 OF 4)
TO FUSE 5 (DIAGRAM 4 OF 4)
VACUUM SOLENOID (SAI)
VIO/RED WIRE
VIO/WHT WIRE
WHT/RED WIRE
WIPER RUN/PARK RELAY
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (4 of 4) -> AUXILIARY LIGHTING SWITCH
Wiring diagram auxiliary lighting switch (5 of 5)
3 4 MS CAN POS MS CAN NEG
32 22 LOGIC GND GND
4 5 MS CAN IN NEG MS CAN IN POS
AUX SW SIG
AUXILIARY LIGHTING SWITCH
BLK WIRE
BOOT OPEN
BOOT RELEASE SW
BRN/VIO WIRE
CENTRAL JUNCTION BOX INTERNAL ELECTRONICS (RIGHT KICK PANEL)
COMPUTER DATA LINES SYSTEM
EXTERNAL TRUNK RELEASE SWITCH
FUEL FLAP
FUEL FLAP MTR
FUEL FLAP RELEASE MOTOR (RIGHT SIDE OF LUGGAGE COMPT)
FUSE 33
FUSE 34
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTERNAL ELECTRONICS
KEYLESS VEHICLE MODULE (LEFT SIDE OF LUGGAGE COMPT)
LOGIC PWR
LUGGAGE COMPARTMENT LID LATCH (CENTER REAR OF TRUNK LID)
LUGGAGE COMPARTMENT LID RELEASE SWITCH, NUMBER PLATE LAMP
MS CAN +
REAR JUNCTION BOX (RIGHT SIDE OF LUGGAGE COMPT)
SOFT TOUCH
TRUNK MTR OPEN
TRUNK RELEASE SWITCH
V BATT
VIO/ORG WIRE
WHT WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Trunk & fuel door release circuit -> AUXILIARY LIGHTING SWITCH
