Jaguar XF I (2007-2011) adaptive damping module Wiring diagram
This page shows the only wiring diagram for the component.adaptive damping module, which is found in the car Jaguar XF I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adaptive damping module (1 of 1)
4.2L 4.2L SC
ACCESSORY RELAY
ADAPTIVE DAMPING MODULE
BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (RIGHT KICK PANEL)
DELAYED POWER OFF RELAY
ENGINE CONTROL MODULE (ECM)
FROM BATTERY JUNCTION BOX (DIAGRAM 1 OF 4)
FROM FUSE 8 (DIAGRAM 2 OF 4)
FROM SPEED CONTROL MODULE (DIAGRAM 2 OF 4)
FROM TRAILER AUXILIARY SOCKET (DIAGRAM 1 OF 4)
FROM TRANSMISSION SHIFT MODULE (DIAGRAM 2 OF 4)
FRONT ACCESSORY SOCKET
FUSE 12
FUSE 26 FUSE 16
FUSE 28
FUSE 35
FUSE 36
FUSE 37
FUSE 38
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
HIGH CURRENT EMS RELAY
IGNITION COIL 1
IGNITION COIL 3
IGNITION COIL 4
IGNITION IGNITION COIL 5 COIL 6
IGNITION IGNITION IGNITION COIL 5 COIL 7 COIL 2
IGNITION IGNITION IGNITION COIL 7 COIL 8 COIL SUPPRESSOR
IGNITION IGNITION IGNITION COIL 8 COIL 6 COIL SUPPRESSOR
IGNITION IGNITION IGNITION IGNITION COIL 2 COIL 1 COIL 3 COIL 4
IGNITION RELAY FUSE 9
INSTRUMENT CLUSTER
INTERNAL ELECTRONICS
INTERNAL POWER DISTRIBUTION
RED WIRE
ROAD PRICING CONNECTOR (BEHIND RIGHT SIDE OF DASH)
SIA RELAY
SPEED PARKING CONTROL BRAKE SENSOR MODULE
SUN BLIND MOTOR
TO ENGINE JUNCTION BOX (DIAGRAM 4 OF 4)
TO FUSE 17 (DIAGRAM 4 OF 4)
TO FUSE 39 (DIAGRAM 4 OF 4)
TO OVERHEAD CONSOLE (DIAGRAM 4 OF 4)
WATER PUMP RELAY (4.2L SC)
WHT WIRE
YEL/GRY WIRE
Go to component -> Power distribution circuit (3 of 4) -> ADAPTIVE DAMPING MODULE
