Jaguar XE I (2015-2019) sim card reader Wiring diagram
This page shows the only wiring diagram for the component.sim card reader, which is found in the car Jaguar XE I (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sim card reader (1 of 1)
AMP
BLK WIRE
BLU WIRE
BR 2 NEG
BR 2 POS
DATA
DIAGNOSTICS 1
DIAGNOSTICS 2
EXTERNAL WIFI ANTENNA
GLOBAL POSITIONING SYSTEM (GPS) ANTENNA
GPS SCN
GPS SIG
GPS SIG SCR GPS SCN
GPS SIGNAL SPLITTER (BEHIND RIGHT REAR SEAT)
GRN WIRE
GSM 1 SIG SCR GSM 1 GND
GSM 1 SIG SCR GSM 1 SCN
GSM 2 GND
GSM 2 SIG
GSM ANTENNA
LEFT "C" PILLAR)
NCA WIRE
ORG/ WIRE
RED WIRE
ROOF POD
SCR BR SHIELD
SCR SHIELD
SHIELD
SIM CARD READER
TCU SCN
TCU SIG
TELEMATIC CONTROL MODULE
W/ GPS SIGNAL SPLITTER
W/O GPS SIGNAL SPLITTER
WHT WIRE
WIFI EXT SIG SCR WIFI EXT GND
YEL WIRE
Go to component -> Telematics circuit (2 of 2) -> SIM CARD READER
