Jaguar XE I (2015-2019) left front recline backrest seat motor Wiring diagrams
This page contains all the electrical diagrams for the component. left front recline backrest seat motor, in which he is found in the car Jaguar XE I (2015-2019). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front recline backrest seat motor (1 of 2)
BATT 1
BATT 2
BATT 3
BLK WIRE
BLU/WHT WIRE
BOLSTER
BOLSTER DEFLATE
BOLSTER INFLATE
BRN/GRN WIRE
BRN/PPL WIRE
CUSHION EXTEND
CUSHION RETRACT
DEFLATE
DOWN
DRIVER LUMBER PUMP
FORWARD/
GND 2
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/PPL WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INFLATE
LEFT CUSHION EXTENSION SEAT MOTOR
LEFT FRONT RECLINE BACKREST SEAT MOTOR
LEFT LUMBAR PUMP
LEFT LUMBAR PUMP SOLENOID
LEFT LUMBAR, BOLSTER SOLENOID
LEFT SEAT FORWARD REARWARD MOTOR
LEFT SEAT HEIGHT MOTOR
LEFT SEAT SWITCHPACK
LEFT SEAT TILT MOTOR
LUMBAR
LUMBAR DOWN
LUMBAR FWD
LUMBAR RWD
LUMBAR UP
PARALLEL DOWN
PARALLEL UP
PASSENGER JUNCTION BOX
PPL
PPL/GRN WIRE
PPL/GRY WIRE
PPL/ORG WIRE
PPL/RED WIRE
PUMP
REARWARD
RED WIRE
SQUAB INCLINE
SQUAB RECLINE
TILT DOWN
TILT UP
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
YEL/PPL WIRE
Go to component -> Power seats circuit, 10-way (1 of 2) -> LEFT FRONT RECLINE BACKREST SEAT MOTOR
Wiring diagram left front recline backrest seat motor (2 of 2)
Go to component -> Power seats circuit, 2-way -> LEFT FRONT RECLINE BACKREST SEAT MOTOR
