Jaguar XE I (2015-2019) left front park assist sensor Wiring diagram
This page shows the only wiring diagram for the component.left front park assist sensor, which is found in the car Jaguar XE I (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front park assist sensor (1 of 1)
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
GRY/ORG WIRE
LEFT FRONT INNER PARKING AID SENSOR
LEFT FRONT OUTER PARKING AID SENSOR
LEFT FRONT PARK ASSIST SENSOR
PPL/GRY WIRE
PWR
RIGHT FRONT INNER PARKING AID SENSOR
RIGHT FRONT OUTER PARKING AID SENSOR
RIGHT FRONT PARK ASSIST SENSOR
SIG
WHT/BLU WIRE
WHT/BRN WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit (2 of 2) -> LEFT FRONT PARK ASSIST SENSOR
