Jaguar XE I (2015-2019) gcu fuse Wiring diagram
This page shows the only wiring diagram for the component.gcu fuse, which is found in the car Jaguar XE I (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gcu fuse (1 of 1)
BATTERY JUNCTION BOX
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BOT CLUTCH SWITCH
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CAN L
CENTER REAR OF LUGGAGE COMPT)
CLUTCH BOT SW
COMPUTER DATA LINES SYSTEM
CRANK REQUEST
DEF HEATING CONTROL MODULE
DEF PRESSURE LINE HEATER
DOWNSTREAM SCR NOX SENSOR
DOWNSTREAM SCR SOOT SENSOR
FRONT ENGINE JUNCTION BOX
FUEL PUMP CTRL
FUEL SENSOR EJECT
FUEL SENSOR PUMP
FUSIBLE LINK 9
GCU FUSE
GLOW 1
GLOW 2
GLOW 3
GLOW 4
GLOW PLUG 1
GLOW PLUG 2
GLOW PLUG 3
GLOW PLUG 4
GLOW PLUG CONTROL MODULE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRY/ORG WIRE
GRY/PPL WIRE
GRY/RED WIRE
GRY/YEL WIRE
GWM HS CAN H
GWM HS CAN L
HOT AT ALL TIMES
I BRK DIAG SW
I BRK SW
IGN
IGNITION 6
LINE HTR PWR
LOCAL CAN NEG
LOCAL CAN POS
MAIN GND
PPL
PPL/BRN WIRE
PPL/GRN WIRE
PPL/ORG WIRE
PPL/WHT WIRE
RED WIRE
SENS GND
SIG
SUPP
SUPPLY
TANK HTR
VBATT
WAKEUP
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/PPL WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/PPL WIRE
Go to component -> Wiring diagram engine performance 2.0l turbo diesel (3 of 8) -> GCU FUSE
