Jaguar XE I (2015-2019) extended ignition mini relay Wiring diagram
This page shows the only wiring diagram for the component.extended ignition mini relay, which is found in the car Jaguar XE I (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram extended ignition mini relay (1 of 1)
11 SPEAKER
17 SPEAKER
AUDIO AMPLIFIER MODULE
BCM-GWM ASSEMBLY
BLK WIRE
BLU WIRE
BLU/RED (OR WHT/RED) WIRE
BLU/RED WIRE
BRN WIRE
DIM FUSE
EXTENDED IGNITION MICRO RELAY
EXTENDED IGNITION MINI RELAY
FROM BATTERY JUNCTION BOX (DIAGRAM 1 OF 8)
FROM VOLTAGE QUALITY MODULE (DIAGRAM 8 OF 8)
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEATED STEERING WHEEL RELAY
HSW FUSE
INSTRUMENT CLUSTER
POWER AMP FUSIBLE LINK
PTC 1 RELAY
PTC 2 RELAY
PTC HEATER 1 FUSIBLE LINK
PTC HEATER 2 FUSIBLE LINK
REAR HEATED SCREEN FUSIBLE LINK
REAR HEATED SCREEN RELAY
REAR JUNCTION BOX
RED WIRE
TCU FUSE
TELEMATIC CONTROL MODULE
TO QUIESCENT CURRENT CONTROL MODULE (DIAGRAM 3 OF 8)
TO REAR JUNCTION BOX (DIAGRAM 7 OF 8)
TO REAR JUNCTION BOX (DIAGRAM 8 OF 8)
TRAILER BRAKE FUSIBLE LINK
W/ START/STOP SYSTEM
W/O START/STOP SYSTEM
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 8) -> EXTENDED IGNITION MINI RELAY
