Jaguar XE I (2015-2019) ext trunk ant pos Wiring diagram
This page shows the only wiring diagram for the component.ext trunk ant pos, which is found in the car Jaguar XE I (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ext trunk ant pos (1 of 1)
BCM-GWM ASSEMBLY (ON PASSENGER JUNCTION BOX)
BLK WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/PPL WIRE
COMPUTER DATA LINES SYSTEM
EXT BOOT REL SW
EXT TRUNK ANT NEG
EXT TRUNK ANT POS
FRONT CABIN ANT NEG
FRONT CABIN ANT POS
FRONT CABIN LF ANTENNA
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/PPL WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HS CAN-H
HS CAN-L
IAU (IMMOBILIZER ANTENNA UNIT) FUSE
ILLUM
IMMOBILIZER ANTENNA UNIT
INSTRUMENT CLUSTER
INT TRUNK ANT NEG
INT TRUNK ANT POS
INTEGRATED CLIMATE CONTROL MODULE, SWITCHPACK
KEYLESS VEHICLE MODULE
KVM LATCH FUSE
KVM LOGIC FUSE
LATCH GND
LATCH SPLY
LEFT LF ANTENNA
LIN 4
LUGGAGE COMPARTMENT RELEASE SWITCH
MS CAN-H
MS CAN-L
PASSENGER JUNCTION BOX
PPL
PPL/GRN WIRE
REAR CABIN ANT NEG
REAR CABIN ANT POS
REAR CENTER CONSOLE LF ANTENNA
REAR EXTERNAL LF ANTENNA
RED WIRE
REL SW
RF RECEIVER
RFR FUSE
RX SERIAL DATA
START STOP
SW GND
VBATT
WHT/ORG WIRE
YEL/ORG WIRE
YEL/PPL WIRE
Go to component -> Anti-theft circuit, passive -> EXT TRUNK ANT POS
