Jaguar XE I (2015-2019) driver window mirror switch pack Wiring diagram
This page shows the only wiring diagram for the component.driver window mirror switch pack, which is found in the car Jaguar XE I (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver window mirror switch pack (1 of 1)
2.0L TURBO DIESEL 3.0L SC 2.0L TURBO W/ LED W/O LED
APPROACH
APPROACH LAMP
AUXILIARY LIGHTING SWITCH
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DC MOTOR GND
DC MOTOR SIG
DC MOTOR SPLY
DI/SML/PD/LDM GND
DRIVER WINDOW MIRROR SWITCH PACK
ENGINE CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
FRONT ENGINE JUNCTION BOX
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/YEL WIRE
HAZARD
HAZARD WARNING SWITCH
HCM FUSE
HIGH MOUNTED STOP LAMP
HIGH/DRL/DI/LDM GND
HIGH/DRL/DI/SML GND
HLL GND
HLL PWR
HLL V
HOT W/ EXTENDED IGNITION RELAY ENERGIZED
ILLUM
INTEGRATED CLIMATE CONTROL MODULE, SWITCH PACK
IS BRK MN
IS BRK RD
LAMP
LDM LIN
LDM SUPPLY
LED
LED ARRAY
LEFT DOOR MIRROR
LEFT FRONT DOOR MODULE
LEFT HEADLAMP
MIRROR GND
MS CAN-H
MS CAN-L
NCA WIRE
NGI HEAD UNIT
NLI HEAD UNIT
PPL/BRN WIRE
PPL/GRN WIRE
PPL/ORG WIRE
PWR
RAIN/LIGHT SENSOR
RED/PPL WIRE
REPEATER
REPEATER LED
RIGHT DOOR MIRROR
RIGHT FOG, TAILLAMP
RIGHT FRONT DOOR MODULE
RIGHT HEADLAMP
RIGHT TAIL/
SIDE MARKER
TAIL
VBATT
W/ START/STOP SYSTEM
WHT/BRN WIRE
YEL/GRY WIRE
YEL/PPL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> DRIVER WINDOW MIRROR SWITCH PACK
