Jaguar X-type I facelift (2008-2009) Shift interlock circuit

24 6 15 5 14 THIRD SWITCH CAN -1 CAN -2 CAN +1 CAN +2 43 27 FOURTH SWITCH SECOND SWITCH BATTERY BLK WIRE BLK/WHT WIRE BLU WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 11 FUSE 31 FUSE 32 FUSE 50 GEARSHIFT INTERLOCK SOLENOID GRN WIRE GROUND HOT AT ALL TIMES HOT IN IGNITION IGNITION SWITCH J GATE MODULE (UNDER CENTER CONSOLE) KEY LOCK SOLENOID MODE SWITCH NOT-IN-PARK SWITCH ORG/ WIRE ORG/YEL WIRE PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) POWER DISTRIBUTION FUSE BOX (ON LEFT SIDE OF ENGINE COMPT) RED WIRE RUN WIRE TRANSMISSION CONTROL MODULE (ON LOWER LEFT "A" PILLAR) WARNING SYSTEM WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
