Exterior lamps circuit, without trailer tow for Jaguar X-type I facelift (2008-2009)

BLK WIRE BLK/GRN WIRE BLK/ORG WIRE BLU WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DIP SIDE AUTO MAIN LIGHT SWITCH OFF FRONT FUSE 29 FUSE 35 FUSE 38 FUSE 55 GENERAL ELECTRONIC CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRN/WHT WIRE HAZARD SWITCH HOT AT ALL TIMES HOT IN RUN INSTRUMENT CLUSTER LEFT TURN RIGHT TURN MASTER LIGHTING SWITCH OFF REAR ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) REAR FOG LAMPS SWITCH RED WIRE TURN SIGNAL AUDIBLE WARNING TURN SIGNAL SWITCH WHT WIRE WHT/BLU WIRE YEL WIRE

2 1 RIGHT FRONT SIDE MARKER LAMP BACK-UP LAMPS CIRCUIT BLK WIRE BLU WIRE BRAKE ON/OFF SWITCH (ABOVE BRAKE PEDAL) BRN WIRE BRN/RED WIRE FOG FUSE 47 FUSE 48 FUSE 51 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HIGH MOUNT STOP LAMP HOT IN RUN LEFT FRONT SIDE MARKER LAMP LEFT FRONT TURN REPEATER LEFT HEADLAMP UNIT LEFT LICENSE PLATE LAMP LEFT REAR SIDE MARKER LAMP LEFT TAIL LAMP UNIT ORG/ WIRE ORG/YEL WIRE PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) RED WIRE REVERSE RIGHT FRONT TURN REPEATER RIGHT HEADLAMP UNIT RIGHT LICENSE PLATE LAMP RIGHT REAR SIDE MARKER LAMP RIGHT TAIL LAMP UNIT SEDAN WAGON SIDE MARKER STOP TAIL TURN TURN SIDE WAGON WAGON 2 1 SEDAN WAGON SEDAN WHT WIRE YEL WIRE
