Jaguar X-type I facelift (2008-2009) Anti-lock brakes circuit, with dynamic stability control

BLK WIRE BLU WIRE BRAKE ON/OFF SWITCH (ABOVE BRAKE PEDAL) BRN WIRE BRN/GRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM CONTROL VALVES DYNAMIC STABILITY CONTROL MODULE (ON RIGHT SIDE OF ENGINE COMPT) DYNAMIC STABILITY CONTROL SWITCH FUSE 13 FUSE 41 FUSE 51 GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ PASSENGER JUNCTION FUSE BOX IGNITION RELAY ENERGIZED HOT W/ POWER DISTRIBUTION FUSE BOX IGNITION RELAY ENERGIZED LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT WHEEL HUB ASSEMBLY) NCA WIRE PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) POWER DISTRIBUTION FUSE BOX (ON LEFT SIDE OF ENGINE COMPT) PRESSURE PUMP RED WIRE RIGHT REAR WHEEL SPEED SENSOR (ON RIGHT REAR WHEEL HUB ASSEMBLY) STEERING ANGLE SENSOR (ON STEERING COLUMN) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YAW RATE SENSOR (BEHIND CENTER CONSOLE) YEL WIRE
