Lumbar circuit for Jaguar X-type I (2001-2009)
Lumbar circuit
BLK WIRE
FUSE 16
HOT AT ALL TIMES
LEFT SEAT LUMBAR PUMP (UNDER LEFT FRONT SEAT)
LEFT SEAT LUMBAR SWITCH PACK
ORG/GRN WIRE
ORG/YEL WIRE
PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE 3
RIGHT SEAT LUMBAR PUMP (UNDER RIGHT FRONT SEAT)
RIGHT SEAT LUMBAR SWITCH PACK
WHT/GRN WIRE
YEL/GRN WIRE
