Instrument cluster circuit for Jaguar X-type I (2001-2009)

AIR BAG IND ANTI-THEFT SYSTEM BATTERY GROUND BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH (ON BRAKE FLUID MASTER CYLINDER) COMPUTER DATA LINES SYSTEM DIMMER IN DIP BEAM IN FUEL LEVEL SENSOR 1 (AT TOP OF FUEL TANK) FUEL LEVEL SENSOR 2 (AT TOP OF FUEL TANK) FUSE 42 FUSE 43 FUSE 45 FUSE 54 GRN WIRE GRN/BLK WIRE GRN/RED WIRE HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM WIPER/WASHER SYSTEM HOT AT ALL TIMES HOT IN IGNITION IGNITION SWITCH INERTIA SW IN INSTRUMENT CLUSTER LOCK MASTER LIGHTING SWITCH MLS/KM OIL PRESS SW ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE PARK BRK SW TRIP CYCLE SW CAN + CAN - FRONT FOG IN REAR FOG IN PASSENGER JUNCTION FUSE BOX (BEHIND LEFT SIDE OF DASH) RED WIRE RESET+ RUN WIRE SCP + SCP - TRIP COMP SW TRIP COMP SW SIDE LAMPS IN SUPPLEMENTAL RESTRAINTS SYSTEM TRIP COMPUTER SWITCHES A/B TURN SIGNAL SWITCH TRIP COMPUTER CYCLE SWITCH WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE
